Gemini D1

฿300.00฿500.00

  • Excellent operating in all positions.
  • Weld bead appearance is smooth with fine ripple formation.

Classification :

  • AWS       SFA 5.1     E 6013

Approvals

  • Lloyds Register of Shipping Grade DXVuO, BF, 2m, NR
  • American Bureau of Shipping Grade 2
  • Thai Industrial Standard (TIS) 49-2528
Clear

Description

Typical Chemical Analysis (All Weld Metal)
% Carbon % Manganese % Silicon
0.07 0.35 0.27



Typical Mechanical Properties
Yield Strength Tensile Strength % Elongation Charpy V-Notch at 0°c
440 N/mm² 540 N/mm² 28 50 J



Positions



Typical Current Values (AC or DC+/-)
Diameter (mm) 2.6 3.2 4.0 5.0
Current    (A) 60 – 80 80 – 120 130 – 160 160 – 210
