Gemini LD52U

  • Suitable for root passes and all positions welding.
  • Extremely stable arc.
  • Not affected by rust or paint on workplace surface.

Classification :

  • AWS A5.1 E7016

Approvals

  • Lloyds Register of Shipping Grade DXVuO, BF, 2m, NR
  • American Bureau of Shipping Grade 2
  • Nippon Kaiji Kyokai (NKK) Grade 2
  • Thai Industrial Standard (TIS) 49-2528

Description

Typical Chemical Analysis (All Weld Metal)
% Carbon % Manganese % Silicon
0.08 0.90 0.45



Typical Mechanical Properties
Yield Strength Tensile Strength % Elongation Impact strength ISO-V @ -20°c
450 N/mm² 560 N/mm² 30 60



Positions



Typical Current Values (AC or DC+/-)
Diameter (mm) 2.6 3.2 4.0 5.0
F, HF, F 60 – 90 A 90 – 130 A 130 – 180 A 180 – 240 A
VU, OH 50 – 80 A 80 – 120 A 110 – 170 A 150 – 200 A
